Troubleshooting Windows Server Backup Failures: Resolving the 'No VSS Writers' Error

Updated: • 0 • min read
Table of Contents

Troubleshooting Windows Server Backup

Windows Server Backup is a crucial tool for maintaining data integrity and enabling disaster recovery. It relies heavily on the Volume Shadow Copy Service (VSS) to create consistent snapshots of volumes, especially when backing up open files or application data. VSS writers are components specifically designed by software vendors (like Microsoft for Exchange, SQL Server, Active Directory, etc., or third-party applications) to ensure that their application data is in a consistent state before the VSS snapshot is taken. If VSS writers fail or are not registered correctly, the VSS process cannot complete successfully, leading to backup failures and potential data inconsistencies in the backup copies.

A common issue encountered by system administrators is the inability of Windows Server Backup to function because the underlying Volume Shadow Copy Service cannot list its available writers. This problem prevents the creation of application-consistent backups, often resulting in crashes or errors during the backup process. When the command vssadmin list writers is executed in the command prompt, instead of displaying a list of healthy VSS writers, the output shows nothing. This indicates a fundamental problem with the VSS infrastructure on the server, directly impacting the reliability and success of backup operations.

Symptoms of Missing VSS Writers

The primary symptom of this issue is the lack of output when running the command vssadmin list writers. A healthy system should display a list of writers associated with installed applications that support VSS, each with a state like “Stable” and a “No error” Last error. When the list is empty, it confirms that the VSS service cannot detect or communicate with any of the registered writers.

Beyond the command-line output, this problem manifests clearly in the Windows Server Backup snap-in. Attempting to open or perform operations within the snap-in often results in an immediate error message indicating a catastrophic failure. This graphical interface error is a direct consequence of the VSS subsystem being non-functional due to the missing writers, as Windows Server Backup depends on VSS to prepare the volumes for backup.

Several error events are typically logged in the Application event log, providing more technical details about the root cause. These events originate from the VSS source. Event ID 34, for instance, reports a “Volume Shadow Copy Service error: The VSS event class is not registered. This will prevent any VSS writers from receiving events.” This error is particularly telling, pointing towards an issue with the VSS eventing mechanism, which is crucial for writers to communicate with the VSS service.

Another significant error is Event ID 8193, often appearing with different hr error codes. An instance showing hr = 0x80040154 signifies REGDB_E_CLASSNOTREG, meaning a class is not registered in the registry. This points towards a problem with COM class registration, which is fundamental to how VSS components interact. Similarly, Event ID 13, reporting “The COM Server with CLSID {faf53cc4-bd73-4e36-83f1-2b23f46e513e} and name VSSEvent cannot be started,” specifically identifies the COM object related to VSS events that cannot be initialized, often paired with hr = 0x80070057, which is E_INVALIDARG, indicating an invalid argument was provided, often relating to incorrect path or configuration data. These log entries collectively confirm a problem with the registration and initialization of core VSS components, preventing writers from functioning.

Understanding VSS and Its Components

To fully appreciate the impact of missing writers, it is helpful to understand the Volume Shadow Copy Service architecture briefly. VSS coordinates activities between three main types of participants:
1. Requestors: These are applications or services that request a shadow copy (e.g., Windows Server Backup, SQL Server, Exchange).
2. Providers: These are components that create and maintain the shadow copies. Microsoft provides a default system provider, but hardware vendors can also supply their own high-performance providers.
3. Writers: These are application-specific components responsible for ensuring that the application data is in a consistent state (e.g., flushing buffers, committing transactions) before the shadow copy is created. This ensures that the backup captures a usable state of the application.


```mermaid
graph LR
A[Requestor
(e.g., Windows Server Backup)] → B(VSS Service);
B → C[VSS Writers
(e.g., SQL Server, Exchange, System Writer)];
C → D{Applications
Data};
B → E[VSS Providers
(e.g., System, Hardware)];
E → F[Volume Shadow Copy];
B → A;
C → B;
E → B;
F → B;



subgraph VSS Ecosystem
    B
    C
    D
    E
    F
end

style B fill:#f9f,stroke:#333,stroke-width:2
style C fill:#ccf,stroke:#333,stroke-width:2
style E fill:#ccf,stroke:#333,stroke-width:2
style F fill:#f9f,stroke:#333,stroke-width:2

```

The errors observed, particularly Event ID 34 and those related to COM registration of the VSSEvent class (CLSID {faf53cc4-bd73-4e36-83f1-2b23f46e513e}), indicate a problem with the VSS service’s ability to communicate with its writers via the COM+ Event System. The VSS event class is how the VSS service notifies writers to prepare for a snapshot. If this class is not correctly registered or accessible, writers cannot receive these notifications and thus cannot participate in the shadow copy process, leading to the “no VSS writers” scenario.

Cause of the Registry Issue

The specific cause identified in the original problem description points to a misconfiguration within the Windows registry related to the VSS event class. The Volume Shadow Copy Service relies on the COM+ Event System to manage communication with VSS writers. The COM+ Event System uses registry entries to define event classes and their associated libraries or executables. For the VSS event class (VSSEvent, CLSID {faf53cc4-bd73-4e36-83f1-2b23f46e513e}), there is a registry key within the EventClasses branch of the COM+ Event System configuration.

The specific key path is HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\EventSystem\{26c409cc-ae86-11d1-b616-00805fc79216}\EventClasses\{FAF53CC4-BD73-4E36-83F1-2B23F46E513E}-{00000000-0000-0000-0000-000000000000}-{00000000-0000-0000-0000-000000000000}. Within this key, there’s a value named TypeLib. This value is supposed to point to the type library containing the definition for the VSSEvent class. The correct file for this is EVENTCLS.DLL, located in the system directory. The issue arises if the data associated with the TypeLib value is incorrect. This could mean the path is wrong, or even the data type of the registry value itself is incorrect, although the provided solution specifically addresses the value data. An incorrect path or data type for this TypeLib entry prevents the COM+ Event System and thus VSS from correctly loading or referencing the necessary component (EVENTCLS.DLL), breaking the communication path to VSS writers.

This specific registry corruption or misconfiguration can occur for various reasons, including system file issues, problems during software installations or uninstallations (particularly backup software, security software, or even application updates that interact with VSS), or potentially manual registry modifications that were done incorrectly. The result is the critical VSSEvent class failing to register or initialize properly, leading directly to the symptoms observed where no VSS writers are listed and backups fail.

Resolution Steps

Resolving this specific issue involves correcting the TypeLib registry value for the VSSEvent class and then restarting the relevant services to ensure the changes take effect. This procedure requires administrative privileges and careful attention when editing the registry. Incorrect registry modifications can cause severe system instability, so it is always recommended to back up the registry or create a system restore point before making changes.

Here are the steps to correct the registry value and resolve the ‘No VSS Writers’ error:

  1. Open Registry Editor:

    • Click on the Start button.
    • Type regedit in the search box.
    • Right-click on regedit.exe in the search results and select Run as administrator. If prompted by User Account Control (UAC), click Yes.

  2. Navigate to the Specific Registry Key:

    • In the Registry Editor window, navigate through the hierarchy in the left pane to locate the following key:
      HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\EventSystem\{26c409cc-ae86-11d1-b616-00805fc79216}\EventClasses\{FAF53CC4-BD73-4e36-83F1-2B23f46e513E}-{00000000-0000-0000-0000-000000000000}-{00000000-0000-0000-0000-000000000000}
    • Ensure you expand HKEY_LOCAL_MACHINE, then SOFTWARE, Microsoft, EventSystem, the long CLSID string {26c409cc-ae86-11d1-b616-00805fc79216}, EventClasses, and finally the even longer key {FAF53CC4-BD73-4e36-83F1-2B23f46e513E}-{00000000-0000-0000-0000-000000000000}-{00000000-0000-0000-0000-000000000000}. Pay close attention to the long key names, ensuring you navigate to the exact path specified.

  3. Locate the TypeLib Value:

    • Once you have selected the correct key in the left pane, look at the values listed in the right pane.
    • Find the value named TypeLib. The data type should ideally be REG_SZ (String Value).

  4. Modify the TypeLib Value Data:

    • Double-click on the TypeLib registry value to open the Edit String dialog box.
    • In the “Value data:” field, ensure the value is exactly: %systemroot%\system32\EVENTCLS.DLL
    • If the value data is different or incorrect, delete the existing content and type the correct path.
    • Click OK to save the change.

  5. Close Registry Editor:

    • Close the Registry Editor window.

  6. Open Services Console:

    • Click on the Start button.
    • Type services.msc in the search box.
    • Press Enter or click on services.msc in the search results. The Services console will open.

  7. Restart Relevant Services:

    • In the Services console, locate the COM+ Event System service.
    • Right-click on COM+ Event System and select Restart. Wait for the service to stop and start again.
    • Next, locate the Volume Shadow Copy service.
    • Right-click on Volume Shadow Copy and select Restart. Wait for the service to stop and start again.
    • It is often beneficial to also restart the Microsoft Software Shadow Copy Provider service if it is running, though not strictly required by the original KB article.

  8. Verify the Fix:

    • Open a Command Prompt as administrator (Search for cmd, right-click, Run as administrator).
    • Type vssadmin list writers and press Enter.
    • Observe the output. You should now see a list of VSS writers with their current state. Ideally, they should all be in a “Stable” state with “No error”.
    • You can also try opening the Windows Server Backup snap-in to see if the catastrophic failure error is gone.

Following these steps corrects the registry entry that the VSS service and COM+ Event System use to locate the necessary component for VSS eventing. Restarting the services ensures that they reload their configuration, picking up the corrected registry value. This should re-establish proper communication between the VSS service and the VSS writers, allowing them to be listed and participate in backup operations.

Further Troubleshooting Tips

While the registry fix is effective for the specific cause outlined, other issues can lead to VSS writer problems or backup failures. If the above steps do not fully resolve the issue or if you encounter other VSS-related errors, consider the following additional troubleshooting steps:

  1. Check VSS Service Dependencies: Ensure that the Volume Shadow Copy service and the COM+ Event System service are running and configured for automatic startup. Also, check their dependencies (listed in the service properties window) to ensure those services are also running correctly.
  2. Check Disk Space: VSS requires free space on each volume being snapshotted (or a designated shadow copy storage volume). Ensure there is sufficient free space (Microsoft recommends at least 15%, though more might be needed depending on volume size and activity).
  3. Run System File Checker: Corrupted system files can impact VSS components. Open Command Prompt as administrator and run sfc /scannow. This utility checks and repairs protected system files.
  4. Check Disk Health: Disk errors can interfere with shadow copy creation. Run chkdsk /f /r on your volumes (this often requires a restart).
  5. Investigate Other Event Logs: Beyond the Application log, check the System log for hardware errors (disk controllers, storage issues) or other service failures that might indirectly affect VSS.
  6. Examine vssadmin Output: If vssadmin list writers still shows issues, try vssadmin list providers and vssadmin list shadows to check the state of other VSS components.
  7. Review Application-Specific VSS Logs: Some applications (like SQL Server or Exchange) have their own VSS-related logging that might provide more specific details if a particular writer is failing.
  8. Check for Software Conflicts: Third-party backup software, antivirus programs, or other system utilities that interact deeply with the storage subsystem can sometimes conflict with VSS. Temporarily disabling such software (in a controlled environment) can help diagnose conflicts.
  9. Permissions: Ensure the System account and other relevant service accounts have necessary permissions on the VSS service, the COM+ Event System, and the relevant registry keys/files.

Resolving VSS issues often requires a systematic approach, starting with the most likely cause (like the registry fix described here) and then expanding the investigation based on error messages and symptoms. A stable and correctly functioning VSS environment is fundamental to reliable data protection on Windows Server.

Conclusion

The ‘No VSS Writers’ error is a significant problem that directly prevents Windows Server Backup and other VSS-aware applications from creating reliable, application-consistent backups. While various factors can contribute to VSS issues, a specific and resolvable cause is related to an incorrect registry entry for the VSS event class (VSSEvent) within the COM+ Event System configuration. By following the detailed steps to correct the TypeLib registry value to %systemroot%\system32\EVENTCLS.DLL and restarting the necessary services, administrators can often quickly restore VSS functionality and enable successful backups.

It is vital to approach registry modifications with caution, ensuring accuracy before applying changes. If the provided resolution does not address the problem, further investigation using system logs and VSS command-line tools is necessary to identify alternative causes, such as service dependencies, resource constraints, or software conflicts. Maintaining the health of the Volume Shadow Copy Service is a critical aspect of server management, ensuring that your disaster recovery strategy remains viable and your data is protected.

Have you encountered this specific VSS error or similar backup failures on your Windows Servers? Share your experiences, troubleshooting steps, or any other solutions you’ve found helpful in the comments below! Engaging with the community helps everyone tackle these common, yet challenging, server issues.
