Resolve WINS Server Errors: Troubleshooting Event IDs 4102, 4243, 4242 & 4286

Updated: • 0 • min read
Table of Contents

The Windows Internet Name Service (WINS) plays a critical role in resolving NetBIOS names to IP addresses in networks where older applications or operating systems still rely on NetBIOS. Proper WINS replication is essential for maintaining a consistent and up-to-date WINS database across multiple servers in the network. When replication fails, it can lead to name resolution issues and impact network connectivity. This article focuses on troubleshooting common WINS replication errors, specifically those indicated by Event IDs 4102, 4243, 4242, and 4286, in environments including Windows Server 2003.

Understanding and addressing these event log messages requires careful examination of the WINS configuration, network connectivity, and sometimes, deep inspection of the network traffic. The data section within each WINS event log message often contains vital clues that pinpoint the source or nature of the problem. By changing the view of the data from bytes to words, administrators can often translate error codes or identify problematic IP addresses.

Understanding WINS Replication Topology

Before delving into specific error messages, it is crucial to ensure that your WINS replication topology is correctly designed and implemented. A true hub-and-spoke model is highly recommended for WINS replication. In this topology, one or more WINS servers act as “hubs,” centralizing updates, while other WINS servers act as “spokes,” replicating only with the hub servers. This prevents complex mesh replication patterns that can lead to inconsistencies and replication loops.

Each WINS server should be configured as its own primary and secondary WINS server to ensure it properly registers its own NetBIOS names. Failure to do so can result in different WINS servers owning names that a particular server registered, leading to resolution problems. Avoiding push-pull replication loops is paramount; the hub-and-spoke model helps enforce this by limiting direct replication partnerships.

```mermaid
graph LR
A[Hub WINS Server 1]
B[Hub WINS Server 2]
C[Spoke WINS Server 1]
D[Spoke WINS Server 2]
E[Spoke WINS Server 3]
F[Spoke WINS Server 4]

C -- Push/Pull --> A
D -- Push/Pull --> A
E -- Push/Pull --> B
F -- Push/Pull --> B
A -- Push/Pull --> B

```
Figure: Example of a Hub-and-Spoke WINS Replication Topology

In this model, Spoke servers replicate only with Hub servers. Hub servers replicate with each other. No Spoke server replicates directly with another Spoke server. This simplifies management and troubleshooting.

Initial Troubleshooting Steps

Regardless of the specific event ID, several fundamental checks should be performed when WINS replication errors occur. Verify network connectivity between the WINS servers involved in replication. Ensure that routers or firewalls separating the servers are not blocking traffic on TCP port 42, which is the port used for WINS replication. A loss of network connection or a failed router on an intermediate link will prevent replication.

Use standard network troubleshooting tools like ping and telnet (on TCP port 42) to test basic connectivity between the replication partners. If these tests fail, the issue lies at a lower network layer and must be resolved before WINS replication can succeed. Once basic connectivity is confirmed, you can use network monitoring tools like Network Monitor to inspect the actual WINS replication traffic on TCP port 42.

WINS Server Error Troubleshooting

WINS Event ID 4243: Communication Failure

WINS Event ID 4243, often translated as WINS_EVT_RPLPULL_PUSH_NTF_EXC, indicates a communication failure during replication. The data section of the event log entry is key to diagnosing this error. Viewing the data section in words can reveal an underlying error code, such as e0000008, which translates to WINS_COMM_FAIL - A communication failure occurred. Check for disconnected or unreachable systems. This clearly points to a network-related issue between the WINS server logging the event and a replication partner.

Possible causes for Event ID 4243 are diverse but centered around connectivity problems or misconfiguration preventing the connection from being established or maintained. An incorrectly configured replication partnership, where a WINS server attempts to replicate with a non-existent or misconfigured partner, is a common culprit. If the WINS service is not running on the replication partner, or if a WINS server is configured as a Pull partner to a system where the WINS service isn’t even installed, this event can occur. Lastly, any general network unreachability of the partner server will trigger this error.

To resolve WINS 4243 events, a network trace is indispensable. Capture traffic on TCP port 42 between the affected WINS server and its partners around the time the event is logged. Look for TCP SYN packets that receive no response (indicating an unreachable host) or TCP Reset packets (indicating the target host actively refused the connection, often because the service isn’t listening on that port). Identify the IP addresses of partners sending Resets or not responding to SYNs; these are likely obsolete or misconfigured partners. Remove these non-functional partners from the WINS server’s replication list.

Resolution Steps for WINS Event ID 4243:

  1. Note the exact timestamp of the 4243 error in the WINS server’s system event log.
  2. Perform a network trace (e.g., using Network Monitor) capturing traffic on TCP port 42 around that timestamp. Filter the trace for TCP SYN and RST flags.
  3. Analyze the trace:
    • Look for TCP SYN packets sent by the logging server that receive no SYN-ACK reply. This suggests the partner is unreachable or blocking the port.
    • Look for TCP SYN packets sent by the logging server that receive an immediate TCP RST reply. This suggests the partner is reachable, but the WINS service is not running or not installed on port 42.
  4. Identify the IP addresses of the partners associated with these failed connection attempts.
  5. On the WINS server logging the error, remove the identified obsolete or misconfigured partners from its list of replication partners.
  6. If using Windows 2000 WINS clusters, ensure replication partners are configured to use the cluster’s virtual IP address, not the physical node IP addresses.

WINS Event ID 4102: Partner Configuration Mismatch

WINS Event ID 4102 is often related to a misconfiguration where replication partners are not mutually configured. This typically occurs when WINS Server A is configured to replicate with WINS Server B (e.g., A is a Pull partner of B), but WINS Server B is not configured to replicate back with WINS Server A (B is not a Push partner of A). The event message itself usually indicates a communication failure during a WINS session setup.

A network trace of a connection attempt leading to a 4102 event reveals the TCP three-way handshake completing successfully, indicating basic network connectivity is fine. However, when the initiating server (the Pull partner in the misconfigured scenario) sends a “WINS Add version Number Map Table Request” message to query for updates, the target server (the one not configured as a partner) responds with a WINS error message like “WINS: Stop Reason = Message Error”. The initiating WINS server then logs the 4102 event and terminates the connection gracefully with a “WINS: Stop Reason = User Initiated” message and a TCP FIN packet.

Possible causes include inconsistent replication partner configurations across your WINS environment. Every push partner should be a pull partner of the target server, and vice-versa, depending on the desired replication flow (though hub-and-spoke reduces the complexity). A rogue WINS server operating unexpectedly on the network could also interfere, potentially causing legitimate servers to attempt replication with it and logging this error.

Resolution Steps for WINS Event ID 4102:

  1. Perform a network trace capturing WINS traffic (TCP port 42) around the time the event occurs.
  2. Identify the remote WINS server that responds with the “WINS: Stop Reason = Message Error” message after receiving a valid WINS request from the server logging the 4102 event. This remote server is the misconfigured partner.
  3. Choose one of the following resolution options:
    • On the WINS server logging the 4102 event, remove the identified remote WINS server from its list of replication partners if that partnership is not intended.
    • On the remote WINS server that sent the “Message Error,” configure it to be a Push partner (or Push/Pull partner, as needed by your topology) of the WINS server that logged the 4102 event. Ensure the partnership is mutual and aligns with your intended topology.
  4. Verify that all WINS servers have their replication partners correctly defined according to your network’s hub-and-spoke structure.

WINS Event ID 4281: Secondary Error

WINS Event ID 4281 is often a secondary symptom rather than a primary issue. The message usually indicates a general failure within the WINS service, but its root cause is typically another, more specific WINS error logged concurrently or just before the 4281 event. The data section contains troubleshooting information, but it’s best interpreted in conjunction with other errors.

Since Event ID 4281 is usually triggered by another underlying problem, the primary step to resolving it is to identify and fix the other WINS error messages appearing in the event log. Once the root cause (like a communication failure, partner misconfiguration, or database issue) is addressed, the 4281 errors should cease. Focus your troubleshooting efforts on the more specific event IDs accompanying the 4281 message.

Similar to Event ID 4281 being a secondary error, WINS Event ID 4242 is often logged when there is a network-related issue impacting WINS communication. The data section of this event will contain details pointing to the specific network error. Because this error code is network-related, the troubleshooting steps largely overlap with those for WINS Event ID 4102 and 4243, which also stem from communication problems.

Review the network connectivity checks outlined previously (ping, telnet TCP 42, firewall rules). If the basic checks pass, employ network monitoring tools to capture WINS traffic on TCP port 42. Look for signs of connection failures, rejected connections, or malformed WINS packets. The analysis techniques described for Event IDs 4243 (looking for connection failures) and 4102 (checking for WINS protocol-level errors like “Message Error”) are applicable here. Address any underlying network path issues or WINS partner misconfigurations identified through the trace.

WINS Event ID 4286: Ephemeral Port Shortage

WINS Event ID 4286 typically occurs on WINS servers that have a large number of replication partners or experience frequent, rapid replication attempts. This error indicates a temporary situation, often resolving itself over time, but it can be disruptive. The most common cause is a shortage of available outgoing TCP ports, also known as ephemeral ports. When a server initiates numerous outgoing connections (like those needed for replication to many partners), it allocates a port for each connection. If the pool of available ports (by default, 1024-5000 on older Windows systems) is exhausted, new connections cannot be established, leading to this error.

The data section of the 4286 event provides specific error codes related to the connection failure. While it resolves over time as ports are freed up, it indicates a potential resource bottleneck.

Resolution Steps for WINS Event ID 4286:

  1. Review your WINS replication topology. Ensure you are using a hub-and-spoke model and that the number of replication partners on any single server is manageable. Excessive partners increase the likelihood of port exhaustion.
  2. Check for a TCP connection shortage on the affected WINS server. Open a command prompt at the time the 4286 errors are occurring and run netstat -a.
  3. Examine the output of netstat -a. Look at the total number of connections and the range of local ports being used. If you see a high number of connections in states like SYN_SENT, ESTABLISHED, TIME_WAIT, and particularly if the local ports used (Local Address column, after the colon) are predominantly within the default ephemeral port range (1024-5000), the server may be running out of ports.
  4. If port exhaustion is indicated, increase the dynamic port range available to the server. This is done by modifying the MaxUserPort value in the registry.
    • Open Registry Editor (regedit).
    • Navigate to HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Tcpip\Parameters.
    • Look for the MaxUserPort DWORD value. If it doesn’t exist, create it.
    • Double-click MaxUserPort and set its value data to 65534 (decimal). This is the maximum allowable value and significantly increases the port pool.
    • Close Registry Editor.
  5. Restart the WINS service or the server for the registry change to take effect.

WINS Event ID 4121 (or 4116 on NT4): No Replication Records Retrieved

WINS Event ID 4121 (on Windows 2000 and later) or 4116 (on Windows NT 4.0) is usually informational and does not necessarily indicate a critical problem, although it might point to potential inefficiencies in replication timing or database maintenance. The translation is WINS_EVT_NO_RPL_RECS_RETRIEVED. This event occurs when a WINS server (the Pull partner) requests updates from another WINS server (the Push partner) based on version IDs it received via push notification, but the requested records no longer exist in the Push partner’s database because they have been updated again or aged out before the Pull partner requested them.

This can happen in fast-changing environments if a Push notification triggers a Pull request, but by the time the Pull happens, the data advertised in the original Push notification has changed or been removed on the Push partner. The data section of the event contains lists of IP addresses and version ID ranges (Min-Version, Max-Version) that the Pull partner requested but couldn’t retrieve. Each line in the data words corresponds to a server from which records were sought, showing the requested version range.

Causes include:
* Push/Pull timing mismatch: The push frequency is too high, or the pull frequency is too low, allowing records to change significantly between notification and retrieval. Tuning the push count and pull time can mitigate this.
* PersonaNonGrata registry entry: If the replication partner is listed in the PersonaNonGrata registry value on the server logging the event, it will refuse to replicate with that partner, potentially leading to this error if requests are still attempted.
* Normal replication behavior: In some scenarios, especially in active networks, a small number of records may become outdated between push notification and pull attempt. If this occurs infrequently and does not cause resolution problems, the event can be considered informational.

This event is logged by default in Windows 2000 and later if “Log detailed events” is enabled. On Windows NT 4.0, it’s only logged when detailed logging is enabled. If the event is frequent and concerning but not causing functional issues, you might consider disabling detailed logging to reduce noise in the event logs.

Disabling Detailed Logging:

  • On Windows NT 4.0:
    1. Open WINS Manager.
    2. On the Server menu, click Configuration.
    3. Click Advanced.
    4. Clear the “Log Detailed Events” check box.
  • On Windows 2000/2003:
    1. Open the WINS snap-in (winsmgmt.msc).
    2. Right-click the WINS server name and select Properties.
    3. Go to the Advanced tab.
    4. Clear the “Log detailed events” check box.

Adjusting the push count and pull time replication settings is often the best approach if these events are frequent and indicate inefficiency. Increase the push count (how many updates trigger a push) and potentially decrease the pull time interval.

Handling a Corrupted WINS Database

In rare cases, WINS replication errors or other issues might stem from a corrupted WINS database on one of the servers. Recovering from a corrupted database requires a specific sequence of steps to minimize impact and restore consistency.

Recovery Steps for a Corrupted WINS Database:

  1. Stop WINS Replication: On the affected server and potentially its direct partners, temporarily disable WINS replication. This prevents the corrupted data from spreading further.
  2. Delete Replication Partners: Remove all replication partners from the server with the potentially corrupted database. This ensures that when replication is re-established, it starts fresh.
  3. Perform Database Compaction (Jetpack): Use the jetpack command-line utility to compact the WINS database file (wins.mdb) while the WINS service is stopped. This removes wasted space and can sometimes resolve corruption issues. First, stop the WINS service. Then, from a command prompt, navigate to the directory containing wins.mdb (usually %SystemRoot%\System32\Wins) and run jetpack wins.mdb temp.mdb. Restart the WINS service after compaction.
  4. Re-establish Replication Partnerships: Manually reconfigure the replication partners on the cleaned-up WINS server, following your established hub-and-spoke topology.
  5. Force Replication: Initiate a manual replication cycle (Push/Pull) from the recovered server to its partners to populate its database with current data from other servers.
  6. Examine Database Consistency: Use the WINS Microsoft Management Console (MMC) snap-in to perform a database consistency check on the recovered server and its partners. This helps verify that the data is synchronizing correctly.

Avoid enabling the “Replicate on Address change” option (or the “When address changes” checkbox in Windows 2000/2003) in large, dynamic environments. This setting can trigger excessive replication, potentially overwhelming servers and contributing to issues like port exhaustion or database strain.

WINS on Server Clusters

Configuring WINS replication on Windows server clusters (specifically Windows NT 4.0 and Windows 2000 clusters) has important differences.

  • Windows 2000/2003 Cluster: Configure WINS replication partners to replicate with the virtual server (using the cluster resource’s virtual IP address) for the WINS service. This allows replication to continue seamlessly even if the WINS resource fails over to another physical node in the cluster. Do not configure replication partnerships with the physical IP addresses of the cluster nodes.
  • Windows NT 4.0 Cluster: WINS service support on NT 4.0 clusters does not include automatic failover for replication partnerships. Therefore, you must configure replication partners to connect to the physical IP addresses of the cluster nodes. If the WINS resource fails over, replication connections targeting the failed node’s IP address will break until manually reconfigured or the original node is restored.

Configuring Network Monitor WINS Parser

Using a network monitor like Network Monitor is crucial for diagnosing complex WINS replication issues. To effectively analyze the specific WINS protocol messages exchanged, you need a WINS parser. The Windows 2000 Server Resource Kit included a WINS Replication Network Monitor parser (Wins.dll).

Steps to Install the WINS Parser:

  1. Obtain the Wins.dll file, potentially from the Windows 2000 Server Resource Kit or a later supplement.
  2. Copy Wins.dll into the Network Monitor parsers directory (typically System32\NetmonFull\Parsers).
  3. Edit the Parser.ini file (located in System32\NetmonFull).
    • Add the following line under the [PARSERS] section:
      wins.dll =0: WINS
    • Add a new section for the WINS parser:
      [WINS]
Comment="WINS Protocol"
FollowSet=
HelpFile=
  4. Edit the Tcpip.ini file (located in System32\NetmonFull\Parsers).
    • Add the following line under the [TCP_HandoffSet] section to associate TCP port 42 with the WINS parser:
      42 = WINS; added
  5. Save both .ini files and restart Network Monitor.

With the parser installed, Network Monitor will display detailed WINS protocol information within captured frames, making it much easier to understand the replication conversation and identify the exact point of failure.

Analyzing network traces with the WINS parser can reveal messages like “Start Association Request/Reply,” “Add version Number Map Table Request,” “Stop Association Message,” and specific error codes or stop reasons exchanged at the W application layer, which is invaluable for troubleshooting Event IDs like 4102 and 4243.

Conclusion

Troubleshooting WINS replication errors like Event IDs 4102, 4243, 4242, and 4286 involves a systematic approach that includes verifying the WINS replication topology, checking fundamental network connectivity, understanding the meaning of event data words, and leveraging network monitoring tools with a WINS parser. While some errors are temporary or informational, others point to critical configuration issues, network blockages, or resource limitations that require specific corrective actions, such as adjusting replication partners, modifying registry settings, or recovering databases. Maintaining a clear hub-and-spoke topology and regularly reviewing WINS server event logs are proactive measures that can help prevent many of these issues.

Have you encountered these WINS event IDs in your environment? What troubleshooting steps did you find most effective? Share your experiences and insights in the comments below!
